替换两个函数,Python版YOLOv5+OpenCV推理帧率提升1.5倍

OpenCV学堂 • 5 月前 • 145 次点击

点击上方蓝字关注我们

微信公众号:OpenCV学堂

关注获取更多计算机视觉与深度学习知识

测试与发现

YOLOv5官方给出的YOLOv5在OpenCV上推理的程序相对来说是比较通俗易懂的,条理清晰,有基本的封装,直接可用!但是我也发现,模型的推理时间跟前后处理的时间相差无几,特别是当视频流有多个检测到的对象时候,整个帧率会有明显下降!官方推荐的参考示例代码链接为:
    https://github.com/doleron/yolov5-opencv-cpp-python/blob/main/python/yolo-tiny.py
    最后发现推理时间没有明显变化,主要是前后处理,有两个函数耗时比较高!从输入图像转换到模型输入数据的函数:
      cv2.dnn.blobFromImage(input_image , 1/255.0, (640, 640), swapRB=True)
      推理之后的重叠目标框非最大抑制函数:
        indexes = cv2.dnn.NMSBoxes(boxes, confidences, 0.25, 0.45)
        特别是非最大抑制函数,随着图像中目标数目增多,导致帧率成明显下降趋势!

        修改输入转换

          cv2.dnn.blobFromImage(input_image , 1/255.0, (640, 640), swapRB=True)

          可以通过下面的代码等价替换:

          rgb = cv.cvtColor(image, cv.COLOR_BGR2RGB)
          input_image = cv.resize(src=rgb, dsize=(INPUT_WIDTH, INPUT_HEIGHT))
          blob_img = np.float32(input_image) / 255.0
          input_x = blob_img.transpose((201))
          input_blob = np.expand_dims(input_x, 0)


          修改之后测试发现该替代降低了执行时间,说明替代有效!


          修改非最大抑制

            indexes = cv2.dnn.NMSBoxes(boxes, confidences, 0.25, 0.45)

            输入的box格式x, y,w,h,我参考了网上的代码,修改实现一个基于并交比最简单的NMS抑制算法,基于矩阵计算,保证不会因为对象变得多了,增加计算耗时,然后把它们封装成一个单独的方法,导入该方法直接替换之前的代码行为:

              class_ids, boxes = non_max_suppression_fast(np.asarray(class_ids), np.asarray(boxes), 0.75)

              该函数完整的实现代码如下:

              import numpy as np


              def non_max_suppression_fast(class_ids, boxes, nms_threshold):
                  # if there are no boxes, return
                  if len(boxes) == 0:
                      return [], []

                  if boxes.dtype.kind == "i":
                      boxes = boxes.astype("float")

                  # initialize the list of picked indexes
                  pick = []

                  # grab the coordinates of the bounding boxes
                  x1 = boxes[:,0]
                  y1 = boxes[:,1]
                  x2 = boxes[:,2]
                  y2 = boxes[:,3]

                  # compute the area of the bounding boxes and sort the bounding
                  # boxes by the bottom-right y-coordinate of the bounding box
                  area = (x2 - x1 + 1) * (y2 - y1 + 1)
                  idxs = np.argsort(y2)

                   # keep looping while some indexes still remain in the indexes
                  # list
                  while len(idxs) > 0:
                      # grab the last index in the indexes list and add the
                      # index value to the list of picked indexes
                      last = len(idxs) - 1
                      i = idxs[last]
                      pick.append(i)

                      # find the largest (x, y) coordinates for the start of
                      # the bounding box and the smallest (x, y) coordinates
                      # for the end of the bounding box
                      xx1 = np.maximum(x1[i], x1[idxs[:last]])
                      yy1 = np.maximum(y1[i], y1[idxs[:last]])
                      xx2 = np.minimum(x2[i], x2[idxs[:last]])
                      yy2 = np.minimum(y2[i], y2[idxs[:last]])

                      # compute the width and height of the bounding box
                      w = np.maximum(0, xx2 - xx1 + 1)
                      h = np.maximum(0, yy2 - yy1 + 1)

                      # compute the ratio of overlap
                      overlap = (w * h) / area[idxs[:last]]

                      # delete all indexes from the index list that have
                      idxs = np.delete(idxs, np.concatenate(([last],
                          np.where(overlap > nms_threshold)[0])))

                  # return only the bounding boxes that were picked using the
                  # integer data type
                  return class_ids[pick], boxes[pick].astype("int")


              if __name__ == "__main__":
                  boxes = []
                  boxes.append((163,   0,  27+163 ,  41))
                  boxes.append((164,   0,  28+164,  43))
                  boxes.append((165,    0,   29+165,   42))
                  res = non_max_suppression_fast(None, np.asarray(boxes), 0.25)
                  print(res)


              对比测试

              两处都修改完成之后,其它输入条件与代码不变,硬件相同条件下对比测试效果如下:修改之前 Python版本OpenCV与OpenVINO上推理速度:


              修改之后 Python版本OpenCV与OpenVINO上推理速度:

              可以看到FPS较之前有明显的提升!
