目录：

• Warmup

• Linear scaling learning rate

• Label-smoothing

• Random image cropping and patching

• Knowledge Distillation

• Cutout

• Random erasing

• Cosine learning rate decay

• Mixup training

• AdaBoud

• AutoAugment

• 其他经典的tricks

Warmup

from torch.optim.lr_scheduler import  _LRScheduler

class  GradualWarmupScheduler(_LRScheduler):
     """
     Args:
         optimizer (Optimizer): Wrapped optimizer.
         multiplier: target learning rate = base lr * multiplier
         total_epoch: target learning rate is reached at total_epoch, gradually
         after_scheduler: after target_epoch, use this scheduler(eg. ReduceLROnPlateau)
     """

     def __init__(self, optimizer, multiplier, total_epoch, after_scheduler=None):
         self.multiplier = multiplier
         if self.multiplier <=  1.:
             raise  ValueError('multiplier should be greater than 1.')
         self.total_epoch = total_epoch
         self.after_scheduler = after_scheduler
         self.finished =  False
         super().__init__(optimizer)

    def get_lr(self):
        if self.last_epoch > self.total_epoch:
            if self.after_scheduler:
                if  not self.finished:
                     self.after_scheduler.base_lrs =  [base_lr * self.multiplier for base_lr in self.base_lrs]
                     self.finished =  True
               return self.after_scheduler.get_lr()
            return  [base_lr * self.multiplier for base_lr in self.base_lrs]

       return  [base_lr *  ((self.multiplier -  1.)  * self.last_epoch / self.total_epoch +  1.)  for base_lr in self.base_lrs]

    def step(self, epoch=None):
        if self.finished and self.after_scheduler:
            return self.after_scheduler.step(epoch)
        else:
            return super(GradualWarmupScheduler, self).step(epoch)

Linear scaling learning rate

Label-smoothing

importtorch
importtorch.nn as nn

class LSR(nn.Module):

    def __init__(self, e=0.1, reduction='mean'):
        super().__init__()

        self.log_softmax = nn.LogSoftmax(dim=1)
        self.e = e
        self.reduction = reduction

    def _one_hot(self, labels, classes, value=1):
        """

           Convert labels to one hot vectors

       Args:
           labels: torch tensor in format [label1, label2, label3, ...]
           classes: int, number of classes
           value: label value in one hot vector, default to 1

      Returns:
          return one hot format labels in shape [batchsize, classes]
      """

      one_hot = torch.zeros(labels.size(0), classes)

      #labels and value_added  size must match
      labels = labels.view(labels.size(0),  -1)
      value_added = torch.Tensor(labels.size(0),  1).fill_(value)

      value_added = value_added.to(labels.device)
      one_hot = one_hot.to(labels.device)

      one_hot.scatter_add_(1, labels, value_added)

      return one_hot

  def _smooth_label(self, target, length, smooth_factor):
      """convert targets to one-hot format, and smooth them.
      Args:
          target: target in form with [label1, label2, label_batchsize]
          length: length of one-hot format(number of classes)
          smooth_factor: smooth factor for label smooth

     Returns:
         smoothed labels in one hot format
     """
     one_hot = self._one_hot(target, length, value=1  - smooth_factor)
     one_hot += smooth_factor / length

     return one_hot.to(target.device)

Random image cropping and patching

beta =  0.3  # hyperparameter
for  (images, targets)  in train_loader:

     # get the image size
     I_x, I_y = images.size()[2:]

     # draw a boundry position (w, h)
     w = int(np.round(I_x * np.random.beta(beta, beta)))
     h = int(np.round(I_y * np.random.beta(beta, beta)))
     w_ =  [w, I_x - w, w, I_x - w]
     h_ =  [h, h, I_y - h, I_y - h]

     # select and crop four images
     cropped_images =  {}
     c_ =  {}
     W_ =  {}
     for k in range(4):
         index = torch.randperm(images.size(0))
         x_k = np.random.randint(0, I_x - w_[k]  +  1)
         y_k = np.random.randint(0, I_y - h_[k]  +  1)
         cropped_images[k]  = images[index][:,  :, x_k:x_k + w_[k], y_k:y_k + h_[k]]
         c_[k]  = target[index].cuda()
         W_[k]  = w_[k]  * h_[k]  /  (I_x * I_y)

     # patch cropped images
     patched_images = torch.cat(
                 (torch.cat((cropped_images[0], cropped_images[1]),  2),
                 torch.cat((cropped_images[2], cropped_images[3]),  2)),
             3)
     #patched_images = patched_images.cuda()

     # get output
     output = model(patched_images)

     # calculate loss and accuracy
     loss = sum([W_[k]  * criterion(output, c_[k])  for k in range(4)])
     acc = sum([W_[k]  * accuracy(output, c_[k])[0]  for k in range(4)])

Knowledge Distillation

Cutout


import torch
import numpy as np

class  Cutout(object):
    """Randomly mask out one or more patches from an image.
    Args:
        n_holes (int): Number of patches to cut out of each image.
        length (int): The length (in pixels) of each square patch.
    """
    def __init__(self, n_holes, length):
        self.n_holes = n_holes
        self.length = length

    def __call__(self, img):
        """
        Args:
            img (Tensor): Tensor image of size (C, H, W).
        Returns:
            Tensor: Image with n_holes of dimension length x length cut out of it.
        """
        h = img.size(1)
        w = img.size(2)

        mask = np.ones((h, w), np.float32)

        for n in range(self.n_holes):
            y = np.random.randint(h)
            x = np.random.randint(w)

            y1 = np.clip(y - self.length //  2,  0, h)
            y2 = np.clip(y + self.length //  2,  0, h)
            x1 = np.clip(x - self.length //  2,  0, w)
            x2 = np.clip(x + self.length //  2,  0, w)

            mask[y1: y2, x1: x2]  =  0.

        mask = torch.from_numpy(mask)
        mask = mask.expand_as(img)
        img = img * mask

        return img

Random erasing

from __future__ import absolute_import
from torchvision.transforms import  *
from PIL import  Image
import random
import math
import numpy as np
import torch

class  RandomErasing(object):
    '''
    probability: The probability that the operation will be performed.
    sh: max erasing area
    r1: min aspect ratio
    mean: erasing value
    '''
    def __init__(self, probability =  0.5, sl =  0.02, sh =  0.4, r1 =  0.3, mean=[0.4914,  0.4822,  0.4465]):
        self.probability = probability
        self.mean = mean
        self.sl = sl
        self.sh = sh
        self.r1 = r1
    def __call__(self, img):
        if random.uniform(0,  1)  > self.probability:
            return img

        for attempt in range(100):
            area = img.size()[1]  * img.size()[2]

            target_area = random.uniform(self.sl, self.sh)  * area
            aspect_ratio = random.uniform(self.r1,  1/self.r1)

            h = int(round(math.sqrt(target_area * aspect_ratio)))
            w = int(round(math.sqrt(target_area / aspect_ratio)))

            if w                 x1 = random.randint(0, img.size()[1]  - h)
                y1 = random.randint(0, img.size()[2]  - w)
                if img.size()[0]  ==  3:
                    img[0, x1:x1+h, y1:y1+w]  = self.mean[0]
                    img[1, x1:x1+h, y1:y1+w]  = self.mean[1]
                    img[2, x1:x1+h, y1:y1+w]  = self.mean[2]
                else:
                    img[0, x1:x1+h, y1:y1+w]  = self.mean[0]




                return img
    return img

Cosine learning rate decay

# Assuming optimizer uses lr = 0.05 for all groups
# lr = 0.05     if epoch
# lr = 0.005    if 30 <= epoch
# lr = 0.0005   if 60 <= epoch

from torch.optim.lr_scheduler import  StepLR
scheduler =  StepLR(optimizer, step_size=30, gamma=0.1)
for epoch in range(100):
    scheduler.step()
    train(...)
    validate(...)

Mixup training

for  (images, labels)  in train_loader:

     l = np.random.beta(mixup_alpha, mixup_alpha)

     index = torch.randperm(images.size(0))
     images_a, images_b = images, images[index]
     labels_a, labels_b = labels, labels[index]

     mixed_images = l * images_a +  (1  - l)  * images_b

     outputs = model(mixed_images)
     loss = l * criterion(outputs, labels_a)  +  (1  - l)  * criterion(outputs, labels_b)
     acc = l * accuracy(outputs, labels_a)[0]  +  (1  - l)  * accuracy(outputs, labels_b)[0]

AdaBound

pip install adabound

optimizer = adabound.AdaBound(model.parameters(), lr=1e-3, final_lr=0.1)

AutoAugment

其他经典的tricks

常用的正则化方法为

• Dropout

• L1/L2正则

• Batch Normalization

• Early stopping

• Random cropping

• Mirroring

• Rotation

• Color shifting

• PCA color augmentation

• ...

其他

• Xavier init[12]

• ...

参考

[1] Deep Residual Learning for Image Recognition(https://arxiv.org/pdf/1512.03385.pdf)

[2] http://cs231n.github.io/neural-networks-2/

[3] Accurate, Large Minibatch SGD: Training ImageNet in 1 Hour(https://arxiv.org/pdf/1706.02677v2.pdf)

[4] Rethinking the Inception Architecture for Computer Vision(https://arxiv.org/pdf/1512.00567v3.pdf)

[5]Bag of Tricks for Image Classification with Convolutional Neural Networks(https://arxiv.org/pdf/1812.01187.pdf)

[6] Adaptive Gradient Methods with Dynamic Bound of Learning Rate(https://www.luolc.com/publications/adabound/)

[7] Random erasing(https://arxiv.org/pdf/1708.04896v2.pdf)

[8] RICAP(https://arxiv.org/pdf/1811.09030.pdf)

[9] Distilling the Knowledge in a Neural Network(https://arxiv.org/pdf/1503.02531.pdf)

[10] Improved Regularization of Convolutional Neural Networks with Cutout(https://arxiv.org/pdf/1708.04552.pdf)

[11] Mixup: BEYOND EMPIRICAL RISK MINIMIZATION(https://arxiv.org/pdf/1710.09412.pdf)

[12] AutoAugment: Learning Augmentation Policies from Data(https://arxiv.org/pdf/1805.09501.pdf)

[13] Understanding the difficulty of training deep feedforward neural networks(http://proceedings.mlr.press/v9/glorot10a/glorot10a.pdf)
